Autoclave Anti-Vibration High Pressure Collet Gland (150,000 psi MAWP)

Name: Autoclave Anti-Vibration High Pressure Collet Gland (150,000 psi MAWP)
Brand: Bishop-Wisecarver
SKU: BEA-a7f93f
Price: 129.99 USD
Availability: OutOfStock

SKU:BEA-a7f93f

Engineered for extreme vibration & shock conditions up to 150,000 psi. Secure, reliable, & economical solution.

$129.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Autoclave Anti-Vibration High Pressure Collet Gland Assembly is engineered for extreme vibration and shock conditions in tubing systems. With pressure capabilities of up to 150,000 psi, this assembly features a unique design that ensures a secure grip on tubing, offering a reliable and economical solution. Utilizing coned-and-threaded connections, this assembly is ideal for demanding environments where stability is crucial.

Product Specifications

Manufacturing Notes 0

For Dimension O: It is recommended that holes to suit bearing mounting studs should be reamed to tolerance F6 for a sliding fit.For 2: Nuts and washers are supplied with both concentric and eccentric RSJ/RLJ type bearings.For Dimension N & R: 'N' is the eccentric offset due to the double eccentric design (2 x N = total stroke). R dimension is both the eccentric offset of the adjusting nut and total stroke at the bearing centerline.For Dimension B1: Controlled height (CHK) bearings are selected in Â±0.010mm bands in respect of the B1 dimension. They are supplied in sets of up to 50 parts as standard, with larger sets on request.For 5: For adjusting tool part numbers see table. For adjustment procedure and fixing nut tightening torques see 58.For 6: Fasteners for the through fixing type bearings are black on the concentric version and bright zinc plated on the eccentric version for identification purposes, except stainless steel type.For Nitrile Seals : Stainless steel bearings are only a

Specifications Adjusting Wrench

AT25

Specifications Controlled Height Chk

Available

Specifications Dimension D 0025

20.27 mm

Specifications Dimension E

10 mm

Specifications Dimension F Metric Fine

M8 x 1

Specifications Dimension G

14 mm

Specifications Dimension H

0.5 mm

Specifications Dimension I

9.8 mm

Specifications Dimension J

1 mm

Specifications Dimension K

5 mm

Specifications Dimension L

3 mm

Specifications Dimension M

13 mm

Specifications Dimension M1

17 mm

Specifications Dimension N

2.75 mm

Specifications Dimension O 00 003

8 mm

Specifications Dimension P

13 mm

Specifications Double Row Dr

Available

Specifications Metal Shields

Available

Specifications Nitrile Seals Ns7

Available

Specifications Socket Tool

RT8

Specifications Twin Bearing

Available

Specifications Weight Rbhjc

43 g

Specifications Weight Rbhje

105 g

Specifications Weight Rljce

51 g

Specifications Weight Rsjce

48 g
