Autoclave High Pressure Anti-Vibration Collet Gland Assembly

Name: Autoclave High Pressure Anti-Vibration Collet Gland Assembly
Brand: Bishop-Wisecarver
SKU: BEA-f96ef3
Price: 129.99 USD
Availability: OutOfStock

SKU:BEA-f96ef3

Reliable Antivibration Collet Gland for Extreme Pressures up to 150,000 psi | Durable Design for Stability

$129.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Enhance tubing system reliability with the Autoclave High Pressure Anti-Vibration Collet Gland Assembly, capable of withstanding pressures up to 150,000 psi. Designed for extreme vibration and shock conditions, this assembly features a tapered, slotted collet and collet nut that securely grips the tubing. The Autoclave coned and threaded connections provide a durable, economical, and easy-to-install solution compared to other vibration-resistant fittings.

Product Specifications

Manufacturing Notes 0

For Dimension O: It is recommended that holes to suit bearing mounting studs should be reamed to tolerance F6 for a sliding fit.For 2: Nuts and washers are supplied with both concentric and eccentric RSJ/RLJ type bearings.For Dimension N & R: 'N' is the eccentric offset due to the double eccentric design (2 x N = total stroke). R dimension is both the eccentric offset of the adjusting nut and total stroke at the bearing centerline.For Dimension B1: Controlled height (CHK) bearings are selected in Â±0.010mm bands in respect of the B1 dimension. They are supplied in sets of up to 50 parts as standard, with larger sets on request.For 5: For adjusting tool part numbers see table. For adjustment procedure and fixing nut tightening torques see 58.For 6: Fasteners for the through fixing type bearings are black on the concentric version and bright zinc plated on the eccentric version for identification purposes, except stainless steel type.For Nitrile Seals : Stainless steel bearings are only a

Specifications Adjusting Wrench

AT13

Specifications Controlled Height Chk

Available

Specifications Dimension D 0025

9.51 mm

Specifications Dimension E

5 mm

Specifications Dimension F Metric Fine

M4 x 0.5

Specifications Dimension G

8 mm

Specifications Dimension H

0.5 mm

Specifications Dimension I

5.8 mm

Specifications Dimension J

0.8 mm

Specifications Dimension K

2.2 mm

Specifications Dimension M

7 mm

Specifications Dimension M1

9 mm

Specifications Dimension N

1.9 mm

Specifications Dimension O 00 003

4 mm

Specifications Dimension P

7 mm

Specifications Double Row Dr

Not Available

Specifications Metal Shields

Not Available

Specifications Nitrile Seals Ns7

Available

Specifications Twin Bearing

Available

Specifications Weight Rbhjc

7 g

Specifications Weight Rbhje

27 g

Specifications Weight Rljce

8 g

Specifications Weight Rsjce

8 g
