Autoclave High Pressure Antivibration Collet Gland Assembly

Name: Autoclave High Pressure Antivibration Collet Gland Assembly
Brand: Bishop-Wisecarver
SKU: BEA-3e1c08
Price: 129.99 USD
Availability: OutOfStock

SKU:BEA-3e1c08

Experience unmatched durability and vibration resistance with the Autoclave High Pressure Antivibration Collet Gland Assembly

$129.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Autoclave High Pressure Antivibration Collet Gland Assembly, part of the High Pressure Fittings and Tubing range, is engineered to withstand extreme vibration/shock conditions, maintaining pressure handling capability up to 20000 psi. With a design that reduces stress concentration on tubing threads, this assembly ensures enhanced durability and virtually unlimited vibrational fatigue life. Made from Type 316 stainless steel with bonded dry film moly lubricant, it offers a cost-effective, reliable, and interchangeable solution for high-pressure systems.

Product Specifications

Manufacturing Notes 0

For Dimension O: It is recommended that holes to suit bearing mounting studs should be reamed to tolerance F6 for a sliding fit.For 2: Nuts and washers are supplied with both concentric and eccentric RSJ/RLJ type bearings.For Dimension N & R: 'N' is the eccentric offset due to the double eccentric design (2 x N = total stroke). R dimension is both the eccentric offset of the adjusting nut and total stroke at the bearing centerline.For Dimension B1: Controlled height (CHK) bearings are selected in Â±0.010mm bands in respect of the B1 dimension. They are supplied in sets of up to 50 parts as standard, with larger sets on request.For 5: For adjusting tool part numbers see table. For adjustment procedure and fixing nut tightening torques see 58.For 6: Fasteners for the through fixing type bearings are black on the concentric version and bright zinc plated on the eccentric version for identification purposes, except stainless steel type.For Nitrile Seals : Stainless steel bearings are only a

Specifications Adjusting Wrench

AT18

Specifications Controlled Height Chk

Available

Specifications Dimension D 0025

14.00 mm

Specifications Dimension E

7 mm

Specifications Dimension F Metric Fine

M6 x 0.75

Specifications Dimension G

10 mm

Specifications Dimension H

0.6 mm

Specifications Dimension I

7.4 mm

Specifications Dimension J

0.8 mm

Specifications Dimension K

3.2 mm

Specifications Dimension L

2.5 mm

Specifications Dimension M

10 mm

Specifications Dimension M1

13 mm

Specifications Dimension N

2.6 mm

Specifications Dimension O 00 003

6 mm

Specifications Dimension P

11 mm

Specifications Double Row Dr

Available

Specifications Metal Shields

Not Available

Specifications Nitrile Seals Ns7

Available

Specifications Socket Tool

RT6

Specifications Twin Bearing

Available

Specifications Weight Rbhjc

18 g

Specifications Weight Rbhje

45 g

Specifications Weight Rljce

20 g

Specifications Weight Rsjce

19 g

Autoclave High Pressure Antivibration Collet Gland Assembly
