Autonics USA 4-Channel Input Recorder
Autonics USA 4-Channel Input Recorder
SKU:PRO-23ba07
Experience precise data recording with the Autonics USA 4-Channel Input Recorder, featuring versatile input support, expandable memory, and robust environmental protection.
Regular price
$1,901.95
Regular price
Sale price
$1,901.95
Unit price
per
Initiate Order
Autonics USA 4-Channel Input Recorder
$1,901.95
Quantity: 1
Claim Your Seller Account
Autonics USA 4-Channel Input Recorder
$1,901.95
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Autonics USA 4-Channel Input Recorder is a cutting-edge device designed for precise data acquisition and recording. With alternating current voltage support ranging from 100 to 240V and a universal input accepting analog and temperature sensor inputs, this recorder ensures versatile compatibility. It offers varying sampling cycles, internal memory of 200MB, expandable to 32GB, and robust environmental protection. Approved by CE and KC, it provides communication outputs via Ethernet, RS 422, RS 485, and USB, making it ideal for industrial monitoring applications.
Product Specifications
Note Note
The weight includes packaging. The weight in parenthesis is for unit only.Environment resistance is rated at no freezing or condensation.
Specifications Alternating Current Ac Voltage
100 to 240 V
Specifications Approval
European Conformity (CE) | Korean Certification (KC)
Specifications Approximate Inner Memory
200 MB
Specifications Communication Output
Ethernet | RS 422 | RS 485 | Universal Serial Bus (USB) Device
Specifications Environment Ambient Relative Humidity Rh
35 to 85 %
Specifications Environment Ambient Storage Relative Humidity Rh
35 to 85 %
Specifications Environment Ambient Temperature
0 to 50 ºC
Specifications Frequency
50 Hz | 60 Hz
Specifications Input And Output Option
None
Specifications List Price
1,901.95 USD
Specifications Maximum External Memory Secure Digital Sd And Uni
32 GB
Specifications Note For Sampling Cycle
Internal sampling period is average movement filter and alarm output operation unit time
Specifications Number Of Inputs
4
Specifications Protection Structure
Ingress Protection (IP) 50 (Front Panel)
Specifications Recording Period
1 to 3600 s
Specifications Sampling Cycle For 1 To 4 Channels
25 ms | 125 ms | 250 ms
Specifications Sampling Cycle For 5 To 16 Channels
125 ms | 250 ms
Specifications Shipping Weight
1290 to 1400 g
Specifications Storage Temperature
-20 to 60 ºC
Specifications Unit Weight
590 to 700 g
Specifications Universal Input
Analog (Voltage, Current (Shunt)) | Temperature Sensors (Thermocouple, Resistance Temperature Detector (RTD))
Specifications Weight
0.2 lb
