Aventics CD07 4-Way Valve Operators
Aventics CD07 4-Way Valve Operators
SKU:DRI-f833f1
Versatile Aventics CD07 4-Way Valve Operators for efficient drilling rig air valve control.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Aventics CD07 4-Way Valve Operators
$45.99
Quantity: 1
Claim Your Seller Account
Aventics CD07 4-Way Valve Operators
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Aventics CD07 4-Way Valve Operators are expertly designed for drilling rig air valve applications in the MMO industry. Featuring a 1/4" NPT port size, stainless steel spools, and a robust zinc die-cast body, these operators offer reliable performance in a compact form. With a working pressure of up to 150 psi and a temperature range from -20 to +175 ºF, they excel in demanding environments. The versatile design enhances equipment appearance while saving engineering space, making operation easy and consistent.
Product Specifications
Specifications Body Material
Zinc Die Casting
Specifications Design
Spring Return
Specifications Flow
Cv = 1.1
Specifications Media
Air (Lubricated or non-lubricated)
Specifications Old Part
PS 034040-0855 | PS 34040-0855 | PS-034040-00855 | PS034040-0855 | PS34040-0855
Specifications Port Size
1/4" NPT
Specifications Spools Material
Stainless Steel
Specifications Temperature Range
-20 to +175 ºF
Specifications Type
Roller
Specifications Working Pressure
150 psi
