Aventics CD07 Plunger Operators
Aventics CD07 Plunger Operators
SKU:DRI-ebd0bc
High-performance Aventics CD07 Plunger Operators for marine, mobile & oil field applications. Durable, compact, and efficient design.
Regular price
$44.99
Regular price
Sale price
$44.99
Unit price
per
Initiate Order
Aventics CD07 Plunger Operators
$44.99
Quantity: 1
Claim Your Seller Account
Aventics CD07 Plunger Operators
$44.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Aventics CD07 Plunger Operators are meticulously crafted with a spring return design, ideal for drilling rig air valves in demanding marine, mobile, and oil field applications. With a 1/4" NPT port size, these operators offer reliable performance under vacuum service up to 150 psi. Constructed with a zinc die-cast body and stainless steel spools, they ensure durability and efficient operation in temperatures ranging from -20 to +175 °F. The compact yet versatile design of the CD07 valves saves engineering space while enhancing equipment appearance, making them a superior choice for industrial settings.
Product Specifications
Specifications Body Material
Zinc Die Casting
Specifications Design
Spring Return
Specifications Flow
Cv = 1.1
Specifications Media
Air (Lubricated or non-lubricated)
Specifications Old Part
PS 034040-5155 | PS 34040-5155 | PS-034040-05155 | PS034040-5155 | PS34040-5155
Specifications Port Size
1/4" NPT
Specifications Spools Material
Stainless Steel
Specifications Temperature Range
-20 to +175 ºF
Specifications Type
Plunger
Specifications Working Pressure
150 psi
