Aventics CD07 Valve Operators
Aventics CD07 Valve Operators
SKU:DRI-0a1867
Compact and durable Aventics CD07 Valve Operators for precise manual control in demanding environments.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Aventics CD07 Valve Operators
$49.99
Quantity: 1
Claim Your Seller Account
Aventics CD07 Valve Operators
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Aventics CD07 Valve Operators offer precise manual and mechanical control with a 4-way, 2-position design. Built for durability, these operators feature a zinc die-cast body and stainless steel spools, ensuring reliable performance in demanding environments. With a compact and versatile structure, these operators save valuable engineering space while enhancing equipment appearance. Ideal for dual pressure applications, these operators have a working pressure of up to 150 psi and are suitable for air media in lubricated or non-lubricated systems. Operating smoothly in temperatures ranging from -20º to +175 ºF, these operators are a dependable choice for various industrial applications.
Product Specifications
Specifications Body Material
Zinc Die Casting
Specifications Design
Detented
Specifications Flow
Cv = 1.1
Specifications Media
Air (Lubricated or non-lubricated)
Specifications Old Part
PS 034040-9155 | PS 34040-9155 | PS-034040-09155 | PS034040-9155 | PS34040-9155
Specifications Port Size
1/4" NPT
Specifications Spools Material
Stainless Steel
Specifications Temperature Range
-20 to +175 ºF
Specifications Type
Rotary Lever
Specifications Working Pressure
150 psi
