Aventics CD07 Valve Operators - 4-Way, 5-Port, Knob Design
Aventics CD07 Valve Operators - 4-Way, 5-Port, Knob Design
SKU:DRI-92031c
Enhance your drilling rig air system with Aventics CD07 Valve Operators for reliable, compact control. Ideal for MMO applications.
Regular price
$44.99
Regular price
Sale price
$44.99
Unit price
per
Initiate Order
Aventics CD07 Valve Operators - 4-Way, 5-Port, Knob Design
$44.99
Quantity: 1
Claim Your Seller Account
Aventics CD07 Valve Operators - 4-Way, 5-Port, Knob Design
$44.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Aventics CD07 Valve Operators offer precise manual and mechanical control in drilling rig air systems. With a 1/4" NPT port size and durable zinc die-cast body paired with stainless steel spools, these operators ensure reliable performance in vacuum to 150 psi applications. Their compact and sleek design not only enhances equipment aesthetics but also optimizes engineering space efficiency. Ideal for MMO environments, these operators guarantee consistent operation in temperatures ranging from -20º to +175 ºF, accommodating both lubricated and non-lubricated air media.
Product Specifications
Specifications Body Material
Zinc Die Casting
Specifications Design
Detented
Specifications Flow
Cv = 1.1
Specifications Media
Air (Lubricated or non-lubricated)
Specifications Old Part
R432016557
Specifications Port Size
1/4" NPT
Specifications Spools Material
Stainless Steel
Specifications Temperature Range
-20 to +175 ºF
Specifications Type
Knob
Specifications Working Pressure
150 psi
