AX97 Power Shielded Inductors
AX97 Power Shielded Inductors
SKU:IND-3201be
Slim, high-performance SMD inductors with low resistance and excellent DC current characteristics. Ideal for laptops, DC/DC converters, and portable communication equipment.
Regular price
$9.99
Regular price
Sale price
$9.99
Unit price
per
Initiate Order
AX97 Power Shielded Inductors
$9.99
Quantity: 1
Claim Your Seller Account
AX97 Power Shielded Inductors
$9.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The AX97 Series SMD Power Shielded Inductors are designed for high performance inductance applications. With a slim profile and low resistance, these inductors offer excellent DC current characteristics, making them ideal for use in a variety of electronic devices. Featuring an inductance of 150.0 µH ±20% and a max DC resistance of 0.890 Ohm, these inductors ensure efficient power transmission and reliable operation. Their compact dimensions and current rating of 0.50 A make them suitable for laptops, DC/DC converters, portable communication equipment, and general-purpose use.
Product Specifications
Applications 0
Laptop and Notebook Computers and PDAsDC/DC ConvertersPortable Communication EquipmentInductor for General Purpose Use
Specifications Current Rating
0.50 A
Specifications Dimension A
0.530 in | 13.46 mm
Specifications Dimension B
0.370 in | 9.40 mm
Specifications Dimension C
0.137 in | 3.50 mm
Specifications Dimension D
0.404 in | 10.26 mm
Specifications Dimension E
0.120 in | 3.05 mm
Specifications Dimension F
0.135 in | 3.43 mm
Specifications Inductance H 20
150.0 µH
Specifications Max Dc Resistance At 25
0.890 Ohm
