AX97 Series Slim SMD Power Shielded Inductors
AX97 Series Slim SMD Power Shielded Inductors
SKU:IND-82e622
Efficient AX97 Series Slim SMD Power Shielded Inductors with 220.0 µH inductance, low 1.300 Ohm resistance, and compact design for versatile applications.
Regular price
$9.99
Regular price
Sale price
$9.99
Unit price
per
Initiate Order
AX97 Series Slim SMD Power Shielded Inductors
$9.99
Quantity: 1
Claim Your Seller Account
AX97 Series Slim SMD Power Shielded Inductors
$9.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The AX97 Series Slim SMD Power Shielded Inductors are designed for excellent DC current characteristics, featuring low resistance for efficient power transfer. With an inductance of 220.0 µH and a max DC resistance of 1.300 Ohm, these inductors are ideal for applications in Laptop and Notebook Computers, PDAs, DC/DC Converters, and Portable Communication Equipment. The compact dimensions make installation easy, meeting the demands of modern electronic devices.
Product Specifications
Applications 0
Laptop and Notebook Computers and PDAsDC/DC ConvertersPortable Communication EquipmentInductor for General Purpose Use
Specifications Current Rating
0.40 A
Specifications Dimension A
0.530 in | 13.46 mm
Specifications Dimension B
0.370 in | 9.40 mm
Specifications Dimension C
0.137 in | 3.50 mm
Specifications Dimension D
0.404 in | 10.26 mm
Specifications Dimension E
0.120 in | 3.05 mm
Specifications Dimension F
0.135 in | 3.43 mm
Specifications Inductance H 20
220.0 µH
Specifications Max Dc Resistance At 25
1.300 Ohm
