Ball Type Check Valves with Threaded Insert and Metal Seat

Name: Ball Type Check Valves with Threaded Insert and Metal Seat
Brand: O'Keefe Controls Co.
SKU: CHE-36f1f4
Price: 34.99 USD
Availability: OutOfStock

SKU:CHE-36f1f4

Reliable Ball Type Check Valves for backflow prevention in fluid systems. Durable construction with 303 SS and Viton seal. Ideal for industrial applications.

$34.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Ball Type Check Valves with Threaded Insert and Metal Seat offer reliable backflow prevention in fluid systems. Constructed with durable materials like 303 SS and Viton seal, these valves ensure long-term performance. With a maximum operating pressure of 200 psig and a maximum temperature of 300 ÂºF, they are suitable for diverse industrial applications. The 304 SS ball material and precise design contribute to a cracking pressure of 0 psid, ensuring efficient operation.

Product Specifications

Dimensions Thread Size

5/16-24

Dimensions Total Length

0.669 in

Specifications Ball Material

304 SS

Specifications Connection A

5/16-24 UNF Threaded Insert O-ring seal

Specifications Cracking Pressure

0 psid

Specifications Cv

0.081

Specifications Material

303 SS

Specifications Maximum Operating Pressure

200 psig

Specifications Maximum Temperature

300 ÂºF

Specifications Screened

None

Specifications Seal Material

Viton

Specifications Thread

Male

Ball Type Check Valves with Threaded Insert and Metal Seat
