Enhance fluid control with our Ball Type NPT Nipple Flow Control Valve. This precision valve features a ball check design and orifice for reliable metered flow. Crafted from durable 303 SS and 304 SS materials, it ensures long-lasting performance in liquids and gases. With a high-pressure capacity and tamperproof design, this valve offers unmatched reliability for various applications. Experience consistent flow control with choice of cracking pressure and all-metal construction.
Product Specifications
Dimensions Orifice Diameter
0.055 in
Dimensions Total Length
1.4 in
Dimensions Width Across Flats Hex
9/16 in
Features Features
All metal construction Long life operation Choice of cracking pressure Tamperproof Orifice High Pressure Capacity
Flow Data Air Flow At 100 Psig
346 to 662 ft³/h
Flow Data Water Flow At 100 Psig
0.8 to 1.6 gpm
Specifications Assembly Forward Cv
0.149
Specifications Ball Material
304 SS
Specifications Check Valve Cv
0.081
Specifications Connection A
1/8" NPT Male
Specifications Connection B
1/8" NPT Male
Specifications Cracking Pressure
0 psig
Specifications Cv Ratio Forward Cv Return Cv
2.19
Specifications Material
303 SS
Specifications Maximum Operating Pressure Gauge
200 psig
Specifications Nominal Orifice Size
55
Specifications Orifice Cv Return
0.068
Specifications Screened
None
