Banjo Polypropylene Full Port Ball Valve - 1 Inch Size
Banjo Polypropylene Full Port Ball Valve - 1 Inch Size
SKU:COU-17b27b
Reliable Banjo Polypropylene Full Port Ball Valve - Ideal for smooth liquid transfer. Self-aligning ball, PTFE seats, fluorocarbon 'O' ring seal, and stainless steel fasteners ensure durability.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Banjo Polypropylene Full Port Ball Valve - 1 Inch Size
$49.99
Quantity: 1
Claim Your Seller Account
Banjo Polypropylene Full Port Ball Valve - 1 Inch Size
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Banjo Polypropylene Full Port Ball Valve, featuring a four-bolt construction, is engineered for precision and reliability. Crafted from reinforced fiberglass polypropylene, this valve ensures exceptional strength. Its self-aligning ball and PTFE seats guarantee smooth operation with minimal handle pressure. With diamond-turned ball for perfect spherical contact, this valve boasts a fluorocarbon 'O' ring stem seal, self-lubricating PTFE bushings, and stainless steel fasteners for corrosion resistance. Ideal for various applications, this lightweight valve is designed for convenient liquid transfer.
Product Specifications
Features
Precision molded in polypropylene. Polypropylene is reinforced with fiberglass for additional strength.Self-aligning ball moves freely against the PTFE seats for smooth operation. The valve opens and closes with very little pressure on the handle.Ball is diamond turned after molding to make it spherically perfect, which provides the right contact between ball and seats.Fluorocarbon (FKM) "O" ring stem seal.PTFE self-lubricating stem bushings and seats cannot stick or rust.Stainless steel nuts and bolts are used to insure easy disassembly in corrosive conditions.Sizes 1/2" thru 2" have a four bolt construction. 2“ full port, and 3" full port have six bolt construction. All have Fluorocarbon (FKM) O-Rings and PTFE seats as a standard.Lightweight hose end valve for convenient transfer of liquids. Angle and flange with 8" long poly propylene fill spout. Same features as straight through valve.
Specifications Construction
Four Bolt Full Port
Specifications Fasteners Material
Stainless steel
Specifications Material
Polypropylene
Specifications Maximum Operating Pressure
100 psi
Specifications O Ring Material
Viton
Specifications Seat Material
PTFE
Specifications Size
1 in
Specifications Stem Material
PTFE
