BCV Series 3/8" FNPT Ball Check Valve
BCV Series 3/8" FNPT Ball Check Valve
SKU:PIS-e28047
High-pressure BCV Series 3/8" FNPT Ball Check Valve for reliable industrial applications.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
BCV Series 3/8" FNPT Ball Check Valve
$39.99
Quantity: 1
Claim Your Seller Account
BCV Series 3/8" FNPT Ball Check Valve
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The BCV Series 3/8" FNPT Ball Check Valve is engineered for optimal performance in high-pressure applications up to 3000 psi. Featuring a 302 Stainless Steel spring with cracking pressures ranging from 1/2 to 70 psi, this brass valve is designed with precision. It offers versatile compatibility with sealing materials like Buna, EPDM, or Fluoroelastomer, ensuring reliable operation in varying conditions. With a maximum operating temperature of 250°F, this valve is suitable for demanding industrial environments where performance and durability are paramount.
Product Specifications
Additional Information Additional Information
The 0.280 flow thru series is available in 1/4 or 3/8 inch Male and Female NPT threads, and sealing materials are Buna, EPDM or Fluoroelastomer. The cracking pressure on the 302 Stainless Steel spring is 1/2 psi, 1 (standard), 3, 6, 10, 30, 40, 55 and 70 psi. The maximum operating pressure is 3000 psi and the maximum operating temperature is 250º F for Buna seals. These Check Valves are designed for high press applications up to 3000 PSI.
Note Note
If you do not see exactly what you are looking for, please contact our sales department.
Technical Specs Series
BCV
Technical Specs Thread Size
3/8 x 3/8 in
Technical Specs Thread Type
Female National Pipe Thread (FNPT) x Female National Pipe Thread (FNPT)
