BG Series 1126W Brushless DC Motor with Integrated Control Electronics
BG Series 1126W Brushless DC Motor with Integrated Control Electronics
SKU:BGS-738ffe
High-performance BG Series 1126W Brushless DC Motor with advanced control for industrial applications.
Regular price
$899.99
Regular price
Sale price
$899.99
Unit price
per
Initiate Order
BG Series 1126W Brushless DC Motor with Integrated Control Electronics
$899.99
Quantity: 1
Claim Your Seller Account
BG Series 1126W Brushless DC Motor with Integrated Control Electronics
$899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The BG Series 1126W Brushless DC Motor with Integrated Control Electronics is a cutting-edge solution for industrial applications. With a nominal current of 20.5A and a nominal output power of 1126W, this motor offers high performance and precise control. Equipped with features like speed, positioning, and current control, as well as inherent overload protection and Smart Diagnostics, it ensures efficient and reliable operation. Compliant with industry standards including CE and UL certifications, this motor guarantees quality and safety for institutional buyers.
Product Specifications
Features Features
Speed- positioning- and current control operationCan be combined with high resolution encoders, brakes and gearboxes in the modular systemControl through bus or I/Os or stand-alone operationHigh IP protection against water or contaminationInherent overload protectionProgrammable with Motion CodeMonitoring with Smart DiagnosticsProfinet version availableEtherCAT version availableEtherNet/IP version availableIO modeSpeed modeCurrent modePositioningDigital inputs configurableAnalog inputsDigital outputsBrake outputProgrammableService interfaceOscilloscope softwareSmart DiagnosticsDigital labelOperating hoursHigh efficiencySinusoidal vector controlInterpolationSSI version availableSafe torque off versionS-RampeOperating hours
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
1100 W
Technical Specs Direct Current Dc Voltage Range
5 to 86 V
Technical Specs Feedback Integrated
4096 cycles/rev
Technical Specs Industry Standardscertifications
China Quality Certification (CQC) | European Conformity (CE) | Underwriters Laboratories (UL)
Technical Specs Maximum Output Power
3865 W
Technical Specs Maximum Torque
11.75 N·m
Technical Specs Nominal Current
20.5 A
Technical Specs Nominal Direct Current Dc Voltage
60 V
Technical Specs Nominal Output Power
1126 W
Technical Specs Nominal Speed
3910 rpm
Technical Specs Nominal Torque
2.75 N·m
Technical Specs Note For Maximum Torque
ÏR = 20ºC
Technical Specs Note For Nominal Current
ÎÏw = 100 K
Technical Specs Note For Nominal Output Power
ÏR = 20ºC
Technical Specs Note For Nominal Speed
ÎÏw = 100 K
Technical Specs Note For Nominal Torque
ÎÏw = 100 K
Technical Specs Note For No Load Speed
ÎÏw = 100 K
Technical Specs Note For Peak Current
ÏR = 20ºC
Technical Specs Note For Torque Constant
At nominal point
Technical Specs No Load Speed
3810 rpm
Technical Specs Peak Current
74 A
Technical Specs Peak Power
4400 W
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP65)
Technical Specs Rotor Inertia
1890 g/cm²
Technical Specs Torque Constant
0.145 N·mA-1
Technical Specs Weight Of Motor
5.1 kg
