BG Series Brushless DC Motor with Integrated Control Electronics
BG Series Brushless DC Motor with Integrated Control Electronics
SKU:BGS-57de99
Enhance control and precision with the BG Series Brushless DC Motor, featuring integrated electronics and high industry certifications for superior performance.
Regular price
$699.99
Regular price
Sale price
$699.99
Unit price
per
Initiate Order
BG Series Brushless DC Motor with Integrated Control Electronics
$699.99
Quantity: 1
Claim Your Seller Account
BG Series Brushless DC Motor with Integrated Control Electronics
$699.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The BG Series Brushless DC Motor offers a seamless integration of control electronics with features like speed, positioning, and current control. With robust industry certifications including CE and UL, this motor ensures high performance and reliability. Its modular design allows for easy combination with encoders, brakes, and gearboxes. Ideal for institutional buyers seeking precision and efficiency.
Product Specifications
Features Features
Speed- positioning- and current control operationCan be combined with high resolution encoders, brakes and gearboxes in the modular systemControl through bus or I/Os or stand-alone operationHigh IP protection against water or contaminationInherent overload protectionProgrammable with Motion CodeMonitoring with Smart DiagnosticsCANopen version availableIO modeSpeed modeCurrent modePositioningBlock commutationDigital inputs configurableAnalog inputsDigital outputsBrake outputProgrammableService interfaceOscilloscope softwareSmart DiagnosticsDigital labelBallast circuitHigh efficiencyOperating hoursVibration resistanceEPLAN Data Portal
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
480 W
Technical Specs Direct Current Dc Voltage Range
2 to 58 V
Technical Specs Feedback Integrated
24 cycles/rev
Technical Specs Industry Standardscertifications
China Quality Certification (CQC) | European Conformity (CE) | Underwriters Laboratories (UL)
Technical Specs Maximum Output Power
1029 W
Technical Specs Maximum Torque
6.58 N·m
Technical Specs Nominal Current
11.26 A
Technical Specs Nominal Direct Current Dc Voltage
48 V
Technical Specs Nominal Output Power
480 W
Technical Specs Nominal Speed
3190 rpm
Technical Specs Nominal Torque
1.436 N·m
Technical Specs Note For Maximum Torque
ÏR = 20ºC
Technical Specs Note For Nominal Current
ÎÏw = 100 K
Technical Specs Note For Nominal Output Power
ÏR = 20ºC
Technical Specs Note For Nominal Speed
ÎÏw = 100 K
Technical Specs Note For Nominal Torque
ÎÏw = 100 K
Technical Specs Note For No Load Speed
ÎÏw = 100 K
Technical Specs Note For Peak Current
ÏR = 20ºC
Technical Specs Note For Torque Constant
At nominal point
Technical Specs No Load Speed
3850 rpm
Technical Specs Peak Current
32.90 A
Technical Specs Peak Power
1029 W
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP65)
Technical Specs Rotor Inertia
652 g/cm²
Technical Specs Torque Constant
0.153 N·mA-1
Technical Specs Weight Of Motor
2.8 kg
