Bird Precision RB82516 Plastic Inline Connector Fitting for 1/16" Tubing
Bird Precision RB82516 Plastic Inline Connector Fitting for 1/16" Tubing
SKU:ORI-09d58b
Enhance tube systems with Bird Precision RB82516 Plastic Inline Connector Fitting for precise flow control.
Regular price
$34.99
Regular price
Sale price
$34.99
Unit price
per
Initiate Order
Bird Precision RB82516 Plastic Inline Connector Fitting for 1/16" Tubing
$34.99
Quantity: 1
Claim Your Seller Account
Bird Precision RB82516 Plastic Inline Connector Fitting for 1/16" Tubing
$34.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your flexible tube systems with the Bird Precision RB82516 Plastic Inline Connector Fitting. This PVDF fitting features a 0.0100" Inner Diameter (I.D.) and 0.030" Outer Diameter (O.D.), ideal for low to high-pressure applications. The sharp edge ruby orifice ensures precise flow control and repeatability, making it a top choice for accuracy-driven projects. With a range of orifice sizes available, this inline connector offers versatility and reliability for various design requirements.
Product Specifications
Additional Information Additional Information
This connector comes with a unique sharp edge ruby orifice series in sizes from 0.0020" thru 0.0130".This Sharp Edge Ruby Orifice series is laser drilled and wire lapped to insure Roundness, surface finish and sharp edges.This orifice series is a good choice where the designer requires low flow, accuracy and repeatability.
Specifications Diameter
0.062 in
Specifications Inside Tubing Diameter
1/16 in
Specifications Material
Plastic
Specifications Orifice Inner Diameter Id
0.0100 in
Specifications Orifice Outer Diameter Od
0.030 in
Specifications Orifice Style
Sharp Edge Ruby Straight-Hole
Specifications Product Style
Inline Connector for Flexible Tube to Tube
Specifications Product Type
Orifice Connectors Fittings
Specifications Series
RB82516
Specifications Suggested Pressures
0.060 O.D. - Low Pressure (Under 150 psi) | 0.118 O.D. - Medium Pressure (5000 psi or lower) | 0.087 O.D. - High Pressure (Above 5000 psi)
