Bisco 1/4-20 Steel Self-Clinching Blind Stud, 77mm Length

Name: Bisco 1/4-20 Steel Self-Clinching Blind Stud, 77mm Length
Brand: bisco industries
SKU: BIS-d8a5a8
Price: 19.99 USD
Availability: OutOfStock

SKU:BIS-d8a5a8

Durable Bisco 1/4-20 Steel Self-Clinching Blind Stud, 77mm length, ideal for industrial applications.

$19.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Bisco 1/4-20 Steel Self-Clinching Blind Stud in 77mm length is a reliable fastening solution designed for industrial and institutional applications. Made of high-quality steel with Zinc and Clear Trivalent Passivation, it offers exceptional durability and corrosion resistance. With a flange diameter of 13.12mm and a tonnage typical range of 5.0 to 10.0mm, this self-clinching stud ensures secure attachment on materials with 0.7 to 3mm thickness. Its coarse 1/4-20 thread size and steel grade 8 construction make it ideal for heavy-duty use. Trust Bisco for robust, compliant fasteners that meet the highest procurement standards.

Product Specifications

Specifications Can Diameter

9.97 mm

Specifications Fastener Type

Self-Clinching

Specifications Flange Diameter

13.12 mm

Specifications Length

77 mm

Specifications Material

Steel

Specifications Material Thickness

0.7 to 3 mm

Specifications Overall Head Height

9.1 mm

Specifications Plating Finish

Zinc and Clear Trivalent Passivation

Specifications Sheet Hole Size

5.1 to 6.9 mm

Specifications Spline Length

4.95 mm

Specifications Steel Grade

Specifications Thread Coarseness

Coarse

Specifications Thread Size

1/4-20

Specifications Tonnage Typical

5.0 to 10.0 mm

Specifications Treatment

Passivated

Bisco 1/4-20 Steel Self-Clinching Blind Stud, 77mm Length
