Bismuth Single Crystal, 2mm Thickness, 12mm Diameter
Bismuth Single Crystal, 2mm Thickness, 12mm Diameter
SKU:BIS-251c39
High-purity Bismuth Single Crystal, 2mm Thickness, 12mm Diameter, Polished Finish
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Bismuth Single Crystal, 2mm Thickness, 12mm Diameter
$49.99
Quantity: 1
Claim Your Seller Account
Bismuth Single Crystal, 2mm Thickness, 12mm Diameter
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Bismuth Single Crystal features precise dimensions of 2mm thickness and 12mm diameter, with a polished surface finish. Made by Goodfellow Corp., it boasts a purity of 99.999% and a specific orientation (111). This material is ideal for applications requiring high-quality single crystals with exceptional thermal and electrical properties, meeting stringent industry standards for performance and reliability.
Product Specifications
Atomic Properties Atomic Number
83
Atomic Properties Atomic Radius Goldschmidt
0 nm
Atomic Properties Atomic Weight
208.98040 amu
Atomic Properties Crystal Structure
Rhombohedral
Atomic Properties Electronic Structure
Xe4f145d106s26p3
Atomic Properties Ionization Potential Number
1 | 2 | 3 | 4 | 5 | 6
Atomic Properties Ionization Potential Number 1
7.29 eV
Atomic Properties Ionization Potential Number 2
16.7 eV
Atomic Properties Ionization Potential Number 3
25.6 eV
Atomic Properties Ionization Potential Number 4
45.3 eV
Atomic Properties Ionization Potential Number 5
56.0 eV
Atomic Properties Ionization Potential Number 6
88.3 eV
Atomic Properties Photo Electric Work Function
4.40 eV
Atomic Properties Thermal Neutron Absorption Cross Section
0.0340 Barns
Atomic Properties Valences Shown
3 | 5
Electrical Properties Electrical Resistivity At 20 Degree Celsiu
117 µΩ·cm
Electrical Properties Temperature Coefficient At 0 To 100 Degree
0.00460 k-1
Electrical Properties Thermal Emf Against Pt Cold 0 Degree Celsi
-7.34 mV
Material Material
BismuthDiscovered in the fifteenth century, although its discoverer is not known. Bismuth is a brittle metal which is silvery in color with a pink tinge. It is stable in air and water. It has poor thermal and electrical properties and finds applications in the manufacture of fusible alloys, a range of materials with low melting points which are suitable for various applications including solders and thermal fuses. Pure bismuth shows a high absorbtion of gamma rays which makes it useful as a filter or window for these particles, whilst at the same time permitting the passage of neutrons.
Mechanical Properties Bulk Modulus Polycrystalline
31.3 GPa
Mechanical Properties Hardness Vickers Polycrystalline
16 to 19 Kgf mm-2
Mechanical Properties Material Condition
Polycrystalline
Mechanical Properties Poissons Ratio Polycrystalline
0.330
Mechanical Properties Tensile Modulus Polycrystalline
34.00 GPa
Physical Properties Boiling Point
1560 ºC
Physical Properties Density At 20 Degree Celsius C Temperature
9.800 g·cm-3
Specifications Diameter
12 mm
Specifications Dummy Orientated Tolerance
3 º
Specifications Form
Single Crystal
Specifications Orientation
111
Specifications Orientation Tolerance
3 º
Specifications Purity
99.999 %
Specifications Quantity
1 Piece
Specifications Surface Finish
Polished on One Side to 1 Micron
Specifications Thickness
2 mm
Thermal Properties Coefficient Of Thermal Expansion At 0 To 100
13.400 x10-6 K-1
Thermal Properties Latent Heat Of Evaporation
857 Jg-1
Thermal Properties Latent Heat Of Fusion
52.00 Jg-1
Thermal Properties Melting Point
271.30 ºC
