Blue 3-Pin Wire Mount Plug Connector
Blue 3-Pin Wire Mount Plug Connector
SKU:PRO-6aaa71
Enhance connectivity with our Blue 3-Pin Wire Mount Plug Connector. Reliable, durable, and compliant with safety standards.
Regular price
$2.10
Regular price
Sale price
$2.10
Unit price
per
Initiate Order
Blue 3-Pin Wire Mount Plug Connector
$2.10
Quantity: 1
Claim Your Seller Account
Blue 3-Pin Wire Mount Plug Connector
$2.10
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your connectivity with our Blue 3-Pin Wire Mount Plug Connector designed for seamless integration in sensor connections. This connector features a strong Terminal Material of C5210 with gold plating, ensuring optimal conductivity and durability. The Body Material of Polycarbonate/ABS and Polycarbonate Case Material meet UL94V-0 standards for fire resistance. With a Maximum Rated Current of 3.0 A and a Voltage rating of ~250 V AC/DC, this connector is reliable and safe for various applications.
Product Specifications
Specifications Body Material
Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0)
Specifications Case Material
Polycarbonate (UL94-V0)
Specifications Color
Blue
Specifications Connector Type
Wire Mount Plug
Specifications Cover Color
Blue
Specifications Cover Diameter
1.2 to 1.6 mm
Specifications List Price
2.10 USD
Specifications Maximum Alternating Current Acdirect Current Dc V
~250 V
Specifications Maximum Insertion Per Pin
1.96 N | 200 gf
Specifications Maximum Rated Current
3.0 A
Specifications Minimum Extraction Per Pin
0.49 N | 50 gf
Specifications Minimum Terminal Retention
1.4 kgf
Specifications Nominal Cross Section Area
0.32 to 0.5 mm²
Specifications Number Of Pins
3
Specifications Terminal Material
C5210 (Gold 0.2 μm)
Specifications Type
Sensor Connector
Specifications Weight
0.56 lb
Specifications Wire Cross Sectional Area
0.32 to 0.5 mm²
Specifications Wire Size
22-20 AWG
