Blue Star Power Systems 150 kW Diesel Generators with John Deere Engine
Blue Star Power Systems 150 kW Diesel Generators with John Deere Engine
SKU:NEW-75ae00
Reliable Blue Star 150 kW Diesel Generators with John Deere Engine, ideal for government and commercial use.
Regular price
$23,500.00
Regular price
Sale price
$23,500.00
Unit price
per
Initiate Order
Blue Star Power Systems 150 kW Diesel Generators with John Deere Engine
$23,500.00
Quantity: 1
Claim Your Seller Account
Blue Star Power Systems 150 kW Diesel Generators with John Deere Engine
$23,500.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Blue Star Power Systems 150 kW Diesel Generators are trusted for their reliable performance and sturdy construction. Featuring a John Deere 6068HF285 engine, these generators operate at 1800 rpm, delivering a maximum standby power of 237 hp | 177 kW·m. The DCP7310 Control Panel offers advanced digital metering, engine protection, and remote communications capabilities. Meeting NFPA 110 Level 1 standards, these generators are ideal for government, institutional, and commercial applications.
Product Specifications
Air Requirements Standby Air Flow Required For Heat Exchangerrem
Consult Factory for Remote Cooled Applications
Air Requirements Standby Air Flow Required For Radiator Cooled U
10,683 ft³/min | 302 m³/min
Air Requirements Standby Aspirating
448 ft³/min | 12.7 m³/min
Cooling System Standby Ambient Capacity Of Radiator
122 ºF | 50.0 ºC
Cooling System Standby Heat Radiated To Ambient
3,021 BTUM | 52.9 kW
Cooling System Standby Heat Rejection To Charge Air Cooler Cac
1,708 BTUM | 29.9 kW
Cooling System Standby Heat Rejection To Coolant
5,407 BTUM | 94.6 kW
Cooling System Standby Maximum Allowable Static Pressure On Radi
0.50 in.H2O | 0.12 kPa
Cooling System Standby Water Pump Flow Rate
48.0 gpm | 182 L/min
Engine Aspiration
Turbo Charged, Charge Air Cooler (CAC)
Engine Bore
4.19 in | 10.6 cm
Engine Compression Ratio
19.0:1
Engine Cylinder Arrangement
6 Cylinder Inline
Engine Displacement
415 in³ | 6.80 L
Engine Manufacturer
John Deere
Engine Maximum Standby Power
237 hp | 177 kW·m
Engine Model
6068HF285
Engine Rated Speed
1800 rpm
Engine Stroke
5.00 in | 12.7 cm
Engine Type
4-Cycle
Exhaust System Standby Gas Temperature Stack
981 ºF | 527 ºC
Exhaust System Standby Gas Volume At Stack Temperature
32.8 ft³/min | 1158 m³/min
Exhaust System Standby Maximum Allowable Exhaust Restriction
7.50 kPa | 30.0 in.H2O
Features Dcp7310 Control Panel Standard Features
Digital MeteringEngine ParametersGenerator Protection FunctionsEngine ProtectionCAN Bus (J1939) ECU CommunicationsWindows-Based SoftwareMultilingual CapabilityRemote Communications to DSE2548 Remote Annunciator8 Programmable Contact Inputs10 Contact OutputsRS485 Communicator InterfacecULus Listed, CE ApprovedEvent RecordingIP 65 rating (with supplied gasket) offers increased resistance to water ingressNFPA 110 Level 1 Compatible
Fluids Capacity Standby Engine Jacket Water Capacity
3.14 gal | 11.9 L
Fluids Capacity Standby System Coolant Capacity
6.10 gal | 23.1 L
Fluids Capacity Standby Total Oil System
5.02 gal | 19.0 L
Fuel Consumption Standby Fuel Consumption At 100 Percent Of Powe
11.1 gal/h | 42.0 L/h
Fuel Consumption Standby Fuel Consumption At 50 Percent Of Power
6.72 gal/h | 25.4 L/h
Fuel Consumption Standby Fuel Consumption At 75 Percent Of Power
8.95 gal/h | 33.9 L/h
Technical Specs Brands
Critical Power Products & Services, LLC
Technical Specs Condition
New
Technical Specs Electrical Power Output
150 kW
Technical Specs Frequency
50 Hz
Technical Specs Fuel Type
Diesel
Technical Specs Item Number
GEN021323CPPS5
Technical Specs Note
Deration Factors: Rated Power is available up to 10,000 ft (3,048 m) at ambient temperatures to 122ËF (50ËC).Consult factory for site conditions above these parameters.
Technical Specs Standard Level
Level II Society of Automotive Engineers (SAE)
