Boron Carbide 1mm Hot-Pressed Sheet
Boron Carbide 1mm Hot-Pressed Sheet
SKU:BOR-6671a8
High-performance 1mm Boron Carbide Sheet with exceptional hardness and chemical resistance. Ideal for demanding applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Boron Carbide 1mm Hot-Pressed Sheet
$49.99
Quantity: 1
Claim Your Seller Account
Boron Carbide 1mm Hot-Pressed Sheet
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Boron Carbide 1mm Hot-Pressed Sheet is a high-performance ceramic material offering exceptional hardness, strength, and wear resistance. With a thickness of 1mm and a size of 25 x 25mm, this sheet is ideal for various applications requiring extreme durability. Its excellent chemical resistance, thermal conductivity, and low porosity make it a reliable choice for demanding environments. Compliance with stringent industry standards ensures quality and reliability for both consumer and institutional buyers.
Product Specifications
Chemical Resistance Alkalis
Fair
Chemical Resistance Concentrated Acids
Fair
Chemical Resistance Dilute Acids
Good
Chemical Resistance Halogens
Fair
Chemical Resistance Metals
Fair
Electrical Properties Volume Resistivity At 25 Degree Celsius C
0.1 to 10 µΩ·cm
Material Material
Boron Carbide - Hot-pressedAfter Diamond, Cubic Boron Nitride and Boron Oxide, Hot pressed Boron Carbide has the highest hardness known. Its main applications make use of its excellent wear resistance and high strength. It has a low density but a high elastic modulus and high compressive strength, which leads to its use as a ballistic material. 20% of natural boron is the 10B isotope, giving Boron Carbide a high neutron capture cross section. It is therefore used in neutron-absorbing applications, such as shielding. Boron carbide has good resistance to acids but not to alkali hydroxide melts.
Mechanical Properties Hardness Knoop
2800 to 3500 Kgf mm-2
Mechanical Properties Hardness Vickers
3200 Kgf mm-2
Mechanical Properties Tensile Modulus
440.00 to 470.00 GPa
Mechanical Properties Tensile Strength
350.00 MPa
Physical Properties Apparent Porosity
< 3.00 %
Physical Properties Density
2.450 to 2.520 g·cm-3
Pultrusion Compressive Strength
1400 to 3400 MPa
Specifications Form
Sheet
Specifications Size
25 x 25 mm
Specifications Thickness
1 mm
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
5.600 x10-6 K-1
Thermal Properties Melting Point
2450.00 ºC
Thermal Properties Specific Heat At 25 Degree Celsius C Temperat
950.0 J K-1 kg-1
Thermal Properties Thermal Conductivity At 20 Degree Celsius C T
30.00 to 90.00 W m-1K-1
Thermal Properties Upper Continuous Use Temperature
600 to 800 ºC
Tolerances Tolerance For 100 Millimeter Mm Coil Length
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Disc Diameter
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Length 1 Light Tight
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Length 2 Light Tight
+2 % | -1 %
Type Type
CeramicCeramics are non-metallic, non-organic materials. They exhibit excellent resistance to high temperatures. Although they have comparatively low densities, they are extremely hard but tend to be brittle. They show good resistance to both abrasives and chemicals.
