Boron Carbide Hot-Pressed Sheet 2mm x 50-200mm
Boron Carbide Hot-Pressed Sheet 2mm x 50-200mm
SKU:BOR-1b2d47
High-performance Boron Carbide Sheet: 2mm thickness, 50-200mm size. Superior strength and resistance to acids. Meets government standards.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
Boron Carbide Hot-Pressed Sheet 2mm x 50-200mm
$299.99
Quantity: 1
Claim Your Seller Account
Boron Carbide Hot-Pressed Sheet 2mm x 50-200mm
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience superior strength and thermal conductivity with our Boron Carbide Hot-Pressed Sheet. With a thickness of 2mm and size ranging from 50mm x 50mm to 50mm x 200mm, this sheet offers exceptional resistance to acids, high hardness, and low density. Ideal for ballistic applications and neutron shielding, it meets stringent government procurement standards for quality and durability.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Chemical Resistance Alkalis
Fair
Chemical Resistance Concentrated Acids
Fair
Chemical Resistance Dilute Acids
Good
Chemical Resistance Halogens
Fair
Chemical Resistance Metals
Fair
Electrical Properties Volume Resistivity At 25 Degree Celsius C
0.1 to 10 µΩ·cm
Material Material
Boron Carbide - Hot-pressedAfter Diamond, Cubic Boron Nitride and Boron Oxide, Hot pressed Boron Carbide has the highest hardness known. Its main applications make use of its excellent wear resistance and high strength. It has a low density but a high elastic modulus and high compressive strength, which leads to its use as a ballistic material. 20% of natural boron is the 10B isotope, giving Boron Carbide a high neutron capture cross section. It is therefore used in neutron-absorbing applications, such as shielding. Boron carbide has good resistance to acids but not to alkali hydroxide melts.
Mechanical Properties Hardness Knoop
2800 to 3500 Kgf mm-2
Mechanical Properties Hardness Vickers
3200 Kgf mm-2
Mechanical Properties Tensile Modulus
440.00 to 470.00 GPa
Mechanical Properties Tensile Strength
350.00 MPa
Physical Properties Apparent Porosity
< 3.00 %
Physical Properties Density
2.450 to 2.520 g·cm-3
Pultrusion Compressive Strength
1400 to 3400 MPa
Specifications Form
Sheet
Specifications Size
50 x 50 to 50 x 200 mm
Specifications Thickness
2 mm
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
5.600 x10-6 K-1
Thermal Properties Melting Point
2450.00 ºC
Thermal Properties Specific Heat At 25 Degree Celsius C Temperat
950.0 J K-1 kg-1
Thermal Properties Thermal Conductivity At 20 Degree Celsius C T
30.00 to 90.00 W m-1K-1
Thermal Properties Upper Continuous Use Temperature
600 to 800 ºC
Tolerances Tolerance For 100 Millimeter Mm Coil Length
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Disc Diameter
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Length 1 Light Tight
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Length 2 Light Tight
+2 % | -1 %
Type Type
CeramicCeramics are non-metallic, non-organic materials. They exhibit excellent resistance to high temperatures. Although they have comparatively low densities, they are extremely hard but tend to be brittle. They show good resistance to both abrasives and chemicals.
