Brass 2/2 Way Manifold Coaxial Valve - CX05PM-2/2-D/C-2/10/100/014/24V-1X
Brass 2/2 Way Manifold Coaxial Valve - CX05PM-2/2-D/C-2/10/100/014/24V-1X
SKU:ACC-e24259
Enhance fluid control with our Brass 2/2 Way Manifold Coaxial Valve - CX Series, featuring brass body, Fluorocarbon & PTFE seals, 100 bar pressure, -10°C to 100°C temp range, 24V, NC switching, IP65 protection, G 1/4 thread, 2.055 kg weight.
Regular price
$189.99
Regular price
Sale price
$189.99
Unit price
per
Initiate Order
Brass 2/2 Way Manifold Coaxial Valve - CX05PM-2/2-D/C-2/10/100/014/24V-1X
$189.99
Quantity: 1
Claim Your Seller Account
Brass 2/2 Way Manifold Coaxial Valve - CX05PM-2/2-D/C-2/10/100/014/24V-1X
$189.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your fluid control systems with our Brass 2/2 Way Manifold Coaxial Valve from the CX Series. This plug-in valve features a brass body with static seal made of Fluorocarbon (FKM) and dynamic seal of Polytetrafluoroethylene (PTFE). With a maximum pressure of 100 bar and operating temperature range of -10°C to 100°C, this electrically actuated valve ensures reliable performance. The IP65 protection level when fitted with a connector plug adds durability and extends service life. Threaded with BSPP G 1/4 connection, this valve is designed for precision and efficient operation in industrial settings. Weighing 2.055 kg, this valve is a versatile and robust solution for various applications.
Product Specifications
Dimensions Height
7.60 in | 193 mm
Dimensions Length
2.05 in | 52 mm
Specifications 3 Day Lead Time
No
Specifications Actuator Type
Electric
Specifications Body Material
Brass
Specifications Degree Of Protection
IP 65 When Fitted with Connector Plug
Specifications Division
ACCESSORIES
Specifications Number Of Ways
2/2
Specifications Operating Pressure Max
100 bar | 1450 psi
Specifications Operating Temperature Max
100 ºC | 212 ºF
Specifications Operating Temperature Min
-10 ºC | 14 ºF
Specifications Pressure Max
100 bar | 1450 psi
Specifications Product
BALL VALVES
Specifications Product Group Family
PROCESS AND AUTOMATED VALVES
Specifications Seal Material
Static Seal: Fluorocarbon (FKM)Dynamic Seal: Polytetrafluoroethylene (PTFE)
Specifications Series
CX Plug-In
Specifications Switching Function
Normally Closed
Specifications Thread Size
G 1/4
Specifications Thread Type
BSPP
Specifications Type
2/2 Way Manifold Coaxial Valve Plug-In
Specifications Voltage
24 V
Specifications Weight
2.055 kg | 4.53 lb
