Brass 90-Degree Male Elbow SAE Fitting - Griplok Series
Brass 90-Degree Male Elbow SAE Fitting - Griplok Series
SKU:SSP-25e5fb
High-quality Brass 90-Degree Male Elbow SAE Fitting for secure and leak-free tubing connections. Ideal for precise instrumentation applications.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Brass 90-Degree Male Elbow SAE Fitting - Griplok Series
$24.99
Quantity: 1
Claim Your Seller Account
Brass 90-Degree Male Elbow SAE Fitting - Griplok Series
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Brass 90-Degree Male Elbow SAE Fitting from the Griplok Series is expertly crafted for precise tubing connections. Constructed with high-quality brass, this fitting ensures durability and reliability. With a 5/8 inch tube fitting size and 7/8-14 Male SAE connection, it offers a secure and leak-free solution. The Griplok design guarantees easy installation and a tight seal, making it ideal for instrumentation applications where precision is paramount.
Product Specifications
Dimensions A
1.56 in
Dimensions Bx
1.16 in
Dimensions By
1.71 in
Dimensions C
0.86 in
Dimensions D
0.96 in
Dimensions E
0.50 in
Dimensions G
1 in
Dimensions H
15/16 in
Dimensions Hx
1 in
Dimensions S
7/8-14
Dimensions T
5/8 in
Specifications As568 O Ring Uniform Size Number
-910
Specifications Body Material
Brass
Specifications Brand Series
Griplok
Specifications Connection 1 Size
5/8 in
Specifications Connection 1 Type
Tube Fitting
Specifications Connection 2 Size
5/8 in
Specifications Connection 2 Type
Male SAE
Specifications End Connections
TF x Male SAE
Specifications Handle Color
0
Specifications Handle Type
0
Specifications Production Category
4
Specifications Shape
Elbow
Category 6
Griplok® Tube Fittings
