Brass Ball Check Valve, 1/4 FNPT x 1/4 MNPT
Brass Ball Check Valve, 1/4 FNPT x 1/4 MNPT
SKU:PIS-547f4b
Reliable BCV Series Brass Ball Check Valve for high-pressure applications with 1/4 FNPT x 1/4 MNPT, ideal for industrial use.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Brass Ball Check Valve, 1/4 FNPT x 1/4 MNPT
$45.99
Quantity: 1
Claim Your Seller Account
Brass Ball Check Valve, 1/4 FNPT x 1/4 MNPT
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The BCV Series Brass Ball Check Valve in 1/4 FNPT x 1/4 MNPT offers reliable flow control in high-pressure applications up to 3000 psi. Featuring a 302 Stainless Steel spring with cracking pressures ranging from 1/2 to 70 psi, this valve ensures a positive seal at high back pressures. With options for Buna, EPDM, or Fluoroelastomer seals, it meets diverse sealing needs. Operating at a maximum temperature of 250°F, this valve is a durable and efficient choice for industrial settings.
Product Specifications
Additional Information Additional Information
The 0.280 flow thru series is available in 1/4 or 3/8 inch Male and Female NPT threads, and sealing materials are Buna, EPDM or Fluoroelastomer. The cracking pressure on the 302 Stainless Steel spring is 1/2 psi, 1 (standard), 3, 6, 10, 30, 40, 55 and 70 psi. The maximum operating pressure is 3000 psi and the maximum operating temperature is 250º F for Buna seals. These Check Valves are designed for high press applications up to 3000 PSI.
Note Note
If you do not see exactly what you are looking for, please contact our sales department.
Technical Specs Series
BCV
Technical Specs Thread Size
1/4 x 1/4 in
Technical Specs Thread Type
Female National Pipe Thread (FNPT) x Male National Pipe Thread (MNPT)
