Brass Ball Check Valve 1/4 MNPT x 1/4 FNPT
Brass Ball Check Valve 1/4 MNPT x 1/4 FNPT
SKU:PIS-b4eddb
Reliable brass ball check valve for high-pressure applications, ensuring efficient flow control and durability.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Brass Ball Check Valve 1/4 MNPT x 1/4 FNPT
$29.99
Quantity: 1
Claim Your Seller Account
Brass Ball Check Valve 1/4 MNPT x 1/4 FNPT
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The BCV Series 1/4 Inch Male National Pipe Thread x 1/4 Inch Female National Pipe Thread Ball Check Valve is a reliable brass valve designed for high-pressure applications up to 2500 psi. Featuring a 302 Stainless Steel spring with various cracking pressures, this valve offers a positive seal under back pressure. With options for different sealing materials like Buna, EPDM, or Fluoroelastomer, this valve ensures versatility and durability. Ideal for industrial and institutional use, this valve guarantees efficient flow control and high performance in various settings.
Product Specifications
Additional Information Additional Information
The 0.280 flow thru series is available in 1/4 or 3/8 inch Male and Female NPT threads, and sealing materials are Buna, EPDM or Fluoroelastomer. The cracking pressure on the 302 Stainless Steel spring is 1/2 psi, 1 (standard), 3, 6, 10, 30, 40, 55 and 70 psi. The maximum operating pressure is 3000 psi and the maximum operating temperature is 250º F for Buna seals. These Check Valves are designed for high press applications up to 3000 PSI.
Note Note
If you do not see exactly what you are looking for, please contact our sales department.
Technical Specs Series
BCV
Technical Specs Thread Size
1/4 x 1/4 in
Technical Specs Thread Type
Female National Pipe Thread (FNPT) x Male National Pipe Thread (MNPT)
