Brass Ball Check Valve BCV Series 1/4in MNPT x 1/4in MNPT
Brass Ball Check Valve BCV Series 1/4in MNPT x 1/4in MNPT
SKU:PIS-d59429
Reliable BCV Series 1/4in MNPT x 1/4in MNPT Ball Check Valve for high-pressure applications, ensures positive seal under back pressure with no elastomers.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Brass Ball Check Valve BCV Series 1/4in MNPT x 1/4in MNPT
$29.99
Quantity: 1
Claim Your Seller Account
Brass Ball Check Valve BCV Series 1/4in MNPT x 1/4in MNPT
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The BCV Series 1/4in MNPT x 1/4in MNPT Ball Check Valve is a reliable choice for high-pressure applications up to 2500 psi. Featuring a 302 Stainless Steel spring with various cracking pressure options, this valve ensures a positive seal under back pressure conditions. With no elastomers for sealing, it minimizes leakage and offers durability. Suitable for 250°F maximum operating temperature, it provides peace of mind in demanding environments.
Product Specifications
Additional Information Additional Information
The 0.280 flow thru series is available in 1/4 or 3/8 inch Male and Female NPT threads, and sealing materials are Buna, EPDM or Fluoroelastomer. The cracking pressure on the 302 Stainless Steel spring is 1/2 psi, 1 (standard), 3, 6, 10, 30, 40, 55 and 70 psi. The maximum operating pressure is 3000 psi and the maximum operating temperature is 250º F for Buna seals. These Check Valves are designed for high press applications up to 3000 PSI.
Note Note
If you do not see exactly what you are looking for, please contact our sales department.
Technical Specs Series
BCV
Technical Specs Thread Size
1/4 x 1/4 in
Technical Specs Thread Type
Male National Pipe Thread (MNPT) x Male National Pipe Thread (MNPT)
