Brass Ball Type Check Valves, Threaded Insert with Metal Seat
Brass Ball Type Check Valves, Threaded Insert with Metal Seat
SKU:CHE-0472f5
High-quality Brass Ball Type Check Valves with Threaded Insert and Metal Seat for precise flow control in industrial applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Brass Ball Type Check Valves, Threaded Insert with Metal Seat
$29.99
Quantity: 1
Claim Your Seller Account
Brass Ball Type Check Valves, Threaded Insert with Metal Seat
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our Brass Ball Type Check Valves with Threaded Insert and Metal Seat are designed for reliable flow control in industrial settings. Constructed with high-quality Brass and a 304 SS Ball, these valves have a CV of 0.190 and can withstand temperatures up to 300°F and pressures up to 200 psig. Featuring a Male Thread and 7/16-20 UNF Threaded Insert O-ring seal connection, these valves have a Cracking Pressure of 2 psid. With a compact Total Length of 0.781 inches, these valves are ideal for applications requiring precision and durability.
Product Specifications
Dimensions Thread Size
7/16-20
Dimensions Total Length
0.781 in
Specifications Ball Material
304 SS
Specifications Connection A
7/16-20 UNF Threaded Insert O-ring seal
Specifications Cracking Pressure
2 psid
Specifications Cv
0.190
Specifications Material
Brass
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Thread
Male
