Brass Ball Type NPT Nipple Flow Control Valve
Brass Ball Type NPT Nipple Flow Control Valve
SKU:FLO-24602a
Enhance flow control with precision. Brass Ball Type NPT Nipple Valve - reliable, tamperproof, precise metered flow for liquids and gases.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Brass Ball Type NPT Nipple Flow Control Valve
$39.99
Quantity: 1
Claim Your Seller Account
Brass Ball Type NPT Nipple Flow Control Valve
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance flow control with our Brass Ball Type NPT Nipple Valve. Featuring an orifice diameter of 0.013 in, this valve ensures precise metered flow suitable for liquids and gases. With a cracking pressure of 10 psig and a high-pressure capacity, this valve guarantees long-lasting performance in industrial settings. The tamperproof design and choice of cracking pressure make it ideal for institutional and government procurement needs.
Product Specifications
Dimensions Orifice Diameter
0.013 in
Dimensions Total Length
1.4 in
Dimensions Width Across Flats Hex
9/16 in
Features Features
All metal construction Long life operation Choice of cracking pressure Tamperproof Orifice High Pressure Capacity
Flow Data Air Flow At 100 Psig
346 to 662 ft³/h
Flow Data Water Flow At 100 Psig
0.8 to 1.6 gpm
Specifications Assembly Forward Cv
0.085
Specifications Ball Material
304 SS
Specifications Check Valve Cv
0.081
Specifications Connection A
1/8" NPT Male
Specifications Connection B
1/8" NPT Male
Specifications Cracking Pressure
10 psig
Specifications Cv Ratio Forward Cv Return Cv
22.32
Specifications Material
Brass
Specifications Maximum Operating Pressure Gauge
200 psig
Specifications Nominal Orifice Size
13
Specifications Orifice Cv Return
0.0038
Specifications Screened
None
