Brass Check Valve, Ball Type - Threaded Insert, Metal Seat
Brass Check Valve, Ball Type - Threaded Insert, Metal Seat
SKU:CHE-616b47
Reliable Brass Check Valve for preventing backflow, with 304 SS ball and Viton seal. Ideal for high-temp applications.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Brass Check Valve, Ball Type - Threaded Insert, Metal Seat
$39.99
Quantity: 1
Claim Your Seller Account
Brass Check Valve, Ball Type - Threaded Insert, Metal Seat
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Brass Check Valve features a durable 304 SS ball for reliable performance. With a Viton seal and a maximum operating pressure of 200 psig, this valve ensures tight sealing and prevents backflow. Its male threaded connection and O-ring seal make installation easy and secure. Ideal for high-temperature applications up to 300 ºF, this valve has a cracking pressure of 15 psid, offering precise control and safety in fluid systems.
Product Specifications
Dimensions Thread Size
7/16-20
Dimensions Total Length
0.781 in
Specifications Ball Material
304 SS
Specifications Connection A
7/16-20 UNF Threaded Insert O-ring seal
Specifications Cracking Pressure
15 psid
Specifications Cv
0.190
Specifications Material
Brass
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Seal Material
Viton
Specifications Thread
Male
