Brass Check Valve with Viton Seal - Ball Type, Threaded Insert
Brass Check Valve with Viton Seal - Ball Type, Threaded Insert
SKU:CHE-38ee7c
Durable Brass Check Valve with Viton Seal, 304 SS Ball, and 200 psig max pressure. Ideal for varied applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Brass Check Valve with Viton Seal - Ball Type, Threaded Insert
$29.99
Quantity: 1
Claim Your Seller Account
Brass Check Valve with Viton Seal - Ball Type, Threaded Insert
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Brass Check Valve with Viton Seal is a durable and reliable solution for controlling flow in various applications. Featuring a 304 SS Ball and a maximum operating pressure of 200 psig, this valve ensures efficient performance under pressure. With a cracking pressure of 2 psid and a maximum temperature resistance of 300°F, it is suitable for a wide range of industrial settings. The threaded insert with O-ring seal provides secure connections, making it ideal for institutional and government procurement requirements.
Product Specifications
Dimensions Thread Size
7/16-20
Dimensions Total Length
0.781 in
Specifications Ball Material
304 SS
Specifications Connection A
7/16-20 UNF Threaded Insert O-ring seal
Specifications Cracking Pressure
2 psid
Specifications Cv
0.190
Specifications Material
Brass
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Seal Material
Viton
Specifications Thread
Male
