Brass Manifold Coaxial Valve - 2 Way, NPT Thread, 40 Bar, Pneumatic
Brass Manifold Coaxial Valve - 2 Way, NPT Thread, 40 Bar, Pneumatic
SKU:ACC-48adeb
Reliable Brass Manifold Coaxial Valve for diverse media, max 40 bar, ideal for 2/2 configurations, with quick 3-day lead time
Regular price
$279.99
Regular price
Sale price
$279.99
Unit price
per
Initiate Order
Brass Manifold Coaxial Valve - 2 Way, NPT Thread, 40 Bar, Pneumatic
$279.99
Quantity: 1
Claim Your Seller Account
Brass Manifold Coaxial Valve - 2 Way, NPT Thread, 40 Bar, Pneumatic
$279.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The CX03M-2/2-D/C/O-2/25/040/100-NPT-M12-3XL Manifold Coaxial Valve is a robust solution crafted from standard brass material, suitable for use with gaseous, liquid, and contaminated media. With a maximum pressure of 40 bar and a wide operating temperature range from -10ºC to 100ºC, this valve functions in normally closed mode with a 2/2 configuration. Its pneumatic actuator and back pressure tolerance of 16 bar ensure reliable performance. This valve has no orientation restrictions for mounting and a quick 3-day lead time for convenience.
Product Specifications
Dimensions Dimension B
246 mm
Dimensions Height
5.69 in
Specifications 3 Day Lead Time
No
Specifications Actuator Type
Pneumatic
Specifications Back Pressure Max
16 bar | 232 psi
Specifications Body Material
Brass (Standard)
Specifications Flow Direction
As Marked
Specifications Media
Gaseous, Liquid, Contaminated
Specifications Mounting Position
No Orientation Restrictions
Specifications Number Of Ways
2/2
Specifications Operating Temperature Max
100 ºC | 212 ºF
Specifications Operating Temperature Min
-10 ºC | 14 ºF
Specifications Pressure Max
40 bar | 580 psi
Specifications Switching Function
Normally Closed
Specifications Thread Size
G 1
Specifications Thread Size 2
G 1
Specifications Thread Type
NPT
Specifications Thread Type 2
NPT
Specifications Type
Manifold Coaxial Valve
Specifications Weight
7.1 kg | 15.65 lb
