Brass Manifold Coaxial Valve - G1/2 Thread, 64 Bar, 24V, Electric Actuator
Brass Manifold Coaxial Valve - G1/2 Thread, 64 Bar, 24V, Electric Actuator
SKU:ACC-484758
High-performance Manifold Coaxial Valve for efficient flow control in diverse applications. Brass construction, 64 bar, 24V, electric actuator.
Regular price
$289.99
Regular price
Sale price
$289.99
Unit price
per
Initiate Order
Brass Manifold Coaxial Valve - G1/2 Thread, 64 Bar, 24V, Electric Actuator
$289.99
Quantity: 1
Claim Your Seller Account
Brass Manifold Coaxial Valve - G1/2 Thread, 64 Bar, 24V, Electric Actuator
$289.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The CX04M-2/2-D/C-2/15/064/012/ 24V-M12-1X is a high-performance Manifold Coaxial Valve designed for efficient control of gaseous, liquid, and contaminated media. With a maximum pressure of 64 bar and operating temperatures ranging from -10ºC to 100ºC, this valve ensures reliable performance. It features a Normally Closed switching function and IP65 degree of protection when fitted with a connector plug. The electric actuator enables precise flow control, while the brass body construction ensures durability and longevity. Ideal for diverse applications with no orientation restrictions, this valve offers exceptional quality and functionality.
Product Specifications
Dimensions Dimension B
184 mm
Dimensions Height
7.24 in
Specifications 3 Day Lead Time
No
Specifications Actuator Type
Electric
Specifications Back Pressure Max
16 bar | 232 psi
Specifications Body Material
Brass (Standard)
Specifications Degree Of Protection
IP 65 When Fitted with Connector Plug
Specifications Division
ACCESSORIES
Specifications Flow Direction
As Marked
Specifications Media
Gaseous, Liquid, Contaminated
Specifications Mounting Position
No Orientation Restrictions
Specifications Number Of Ways
2/2
Specifications Operating Temperature Max
100 ºC | 212 ºF
Specifications Operating Temperature Min
-10 ºC | 14 ºF
Specifications Pressure Max
64 bar | 928 psi
Specifications Product
BALL VALVES
Specifications Product Group Family
PROCESS AND AUTOMATED VALVES
Specifications Switching Function
Normally Closed
Specifications Thread Size
G 1/2
Specifications Thread Size 2
G 1/2
Specifications Thread Type
BSPP
Specifications Thread Type 2
BSPP
Specifications Type
Manifold Coaxial Valve
Specifications Voltage
24 V
Specifications Weight
3.6 kg | 7.94 lb
