Brass Manifold Coaxial Valve - Thread Type BSPP, 2/2 Way, 120 bar
Brass Manifold Coaxial Valve - Thread Type BSPP, 2/2 Way, 120 bar
SKU:ACC-117f29
High-quality brass manifold coaxial valve for diverse media, with max 120 bar pressure & -10 to 100 ºC operating temp.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Brass Manifold Coaxial Valve - Thread Type BSPP, 2/2 Way, 120 bar
$89.99
Quantity: 1
Claim Your Seller Account
Brass Manifold Coaxial Valve - Thread Type BSPP, 2/2 Way, 120 bar
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The CX07M-2/2-F/O-2/10/120/012-1X-IN-M6 is a high-quality brass manifold coaxial valve designed for gaseous, liquid, and contaminated media. With a maximum pressure of 120 bar and operating temperatures ranging from -10 ºC to 100 ºC, this valve ensures reliable performance in diverse environments. Featuring a pneumatic actuator and normally open switching function, this valve offers seamless flow direction control with a maximum back pressure of 16 bar. Its robust design, no orientation restrictions for mounting, and quick 3-day lead time make it ideal for applications requiring precision and efficiency.
Product Specifications
Specifications 3 Day Lead Time
No
Specifications Actuator Type
Pneumatic
Specifications Back Pressure Max
16 bar | 232 psi
Specifications Body Material
Brass (Standard)
Specifications Division
ACCESSORIES
Specifications Flow Direction
As Marked
Specifications Media
Gaseous, Liquid, Contaminated
Specifications Mounting Position
No Orientation Restrictions
Specifications Number Of Ways
2/2
Specifications Operating Temperature Max
100 ºC | 212 ºF
Specifications Operating Temperature Min
-10 ºC | 14 ºF
Specifications Pressure Max
120 bar | 1740 psi
Specifications Product
BALL VALVES
Specifications Product Group Family
PROCESS AND AUTOMATED VALVES
Specifications Switching Function
Normally Open
Specifications Thread Type
BSPP
Specifications Type
Manifold Coaxial Valve
