Brass Threaded Check Valves with Fluorocarbon Seal

Name: Brass Threaded Check Valves with Fluorocarbon Seal
Brand: O'Keefe Controls Co.
SKU: CHE-1ea97b
Price: 25.99 USD
Availability: OutOfStock

SKU:CHE-1ea97b

Durable Brass Threaded Check Valves with Fluorocarbon seal for reliable performance. Ideal for industrial applications.

$25.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Upgrade your plumbing system with our Brass Threaded Check Valves featuring a durable Fluorocarbon seal for enhanced performance. With a low leakage rate, all-metal construction, and a maximum operating pressure of 875 kPa, these valves ensure reliability and long-lasting operation. Ideal for industrial applications requiring precision and efficiency.

Product Specifications

Dimensions Nose Diameter

4.45 mm

Dimensions Orifice Diameter

0.017 in | 0.43 mm

Dimensions Thread Size

Dimensions Total Length

12.7 mm

Dimensions Width Across Flats Hex

3 mm

Features Features

All metal construction option Long life operation Low cost

Specifications Ball Material

Fluorocarbon

Specifications Connection A

M6 Threaded Insert O-Ring seal

Specifications Cv

0.0067

Specifications Hex Type

Internal

Specifications Material

Brass

Specifications Maximum Operating Pressure

875 kPa

Specifications Maximum Temperature

120 ÂºF

Specifications Nominal Orifice Size

Specifications Screened

None

Specifications Seal Material

Fluorocarbon

Specifications Seat Leakage

6 SCCM (max.) air flow at greater than 50 psi differential

Specifications Thread

Male

Brass Threaded Check Valves with Fluorocarbon Seal
