Brass Threaded Check Valves with Nitrile Seal

Name: Brass Threaded Check Valves with Nitrile Seal
Brand: O'Keefe Controls Co.
SKU: CHE-2c2f3d
Price: 29.99 USD
Availability: OutOfStock

SKU:CHE-2c2f3d

High-performance Brass Check Valves with Fluorocarbon ball and Nitrile seal. Ensures safety and longevity for industrial operations.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Upgrade your industrial operations with our Brass Threaded Check Valves featuring a Fluorocarbon ball, ideal for high-pressure applications. With a seal leakage of 6 SCCM at greater than 50 psi, these valves ensure maximum safety. The all-metal construction guarantees longevity and cost-effectiveness, meeting stringent institutional procurement standards effortlessly.

Product Specifications

Dimensions Nose Diameter

5.59 mm

Dimensions Orifice Diameter

0.04 in | 1.02 mm

Dimensions Thread Size

Dimensions Total Length

16.3 mm

Dimensions Width Across Flats Hex

4 mm

Features Features

All metal construction option Long life operation Low cost

Specifications Ball Material

Fluorocarbon

Specifications Connection A

M8 Threaded Insert O-Ring seal

Specifications Cv

0.036

Specifications Hex Type

Internal

Specifications Material

Brass

Specifications Maximum Operating Pressure

875 kPa

Specifications Maximum Temperature

120 ÂºF

Specifications Nominal Orifice Size

Specifications Screened

None

Specifications Seal Material

Nitrile

Specifications Seat Leakage

6 SCCM (max.) air flow at greater than 50 psi differential

Specifications Thread

Male

Brass Threaded Check Valves with Nitrile Seal
