Brass Threaded Check Valves with Nitrile Seal

Name: Brass Threaded Check Valves with Nitrile Seal
Brand: O'Keefe Controls Co.
SKU: CHE-d48c39
Price: 29.99 USD
Availability: OutOfStock

SKU:CHE-d48c39

Durable Brass Check Valves with Nitrile Seal for reliable performance and easy installation in industrial settings.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Our Brass Threaded Check Valves with Nitrile Seal are engineered for reliable performance in various applications. With a Nitrile seal and Brass construction, these valves ensure durability and resistance to leaks. The threaded insert design with nose seal enhances installation security, making them ideal for industrial settings. Meeting stringent standards, these valves provide exceptional functionality and longevity, making them a cost-effective choice for institutional and government procurement needs.

Product Specifications

Dimensions Nose Diameter

5.59 mm

Dimensions Orifice Diameter

0.013 in | 0.33 mm

Dimensions Thread Size

Dimensions Total Length

16.3 mm

Dimensions Width Across Flats Hex

4 mm

Features Features

All metal construction option Long life operation Low cost

Specifications Ball Material

Nitrile

Specifications Connection A

M8 Threaded Insert O-Ring seal

Specifications Cv

0.0038

Specifications Hex Type

Internal

Specifications Material

Brass

Specifications Maximum Operating Pressure

875 kPa

Specifications Maximum Temperature

65 ÂºF

Specifications Nominal Orifice Size

Specifications Screened

None

Specifications Seal Material

Nitrile

Specifications Seat Leakage

6 SCCM (max.) air flow at greater than 50 psi differential

Specifications Thread

Male

Brass Threaded Check Valves with Nitrile Seal
