Brass Threaded Check Valves with Nitrile Seal
Brass Threaded Check Valves with Nitrile Seal
SKU:CHE-35393f
High-performance Brass Threaded Check Valves with Nitrile Seal for reliable flow control in industrial settings.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Brass Threaded Check Valves with Nitrile Seal
$29.99
Quantity: 1
Claim Your Seller Account
Brass Threaded Check Valves with Nitrile Seal
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your plumbing system with our Brass Threaded Check Valves featuring a reliable Nitrile Seal for secure flow control. Made with high-quality materials and precision engineering, these check valves ensure long-lasting performance, low leakage rates, and cost-effectiveness. With a maximum operating pressure of 875 kPa and a temperature tolerance up to 120 ºF, these valves are ideal for industrial applications requiring durability and efficiency.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Nose Diameter
4.45 mm
Dimensions Orifice Diameter
0.039 in | 0.99 mm
Dimensions Thread Size
M6
Dimensions Total Length
12.7 mm
Dimensions Width Across Flats Hex
3 mm
Features Features
All metal construction option Long life operation Low cost
Specifications Ball Material
Fluorocarbon
Specifications Connection A
M6 Threaded Insert O-Ring seal
Specifications Cv
0.033
Specifications Hex Type
Internal
Specifications Material
Brass
Specifications Maximum Operating Pressure
875 kPa
Specifications Maximum Temperature
120 ºF
Specifications Nominal Orifice Size
39
Specifications Screened
None
Specifications Seal Material
Nitrile
Specifications Seat Leakage
6 SCCM (max.) air flow at greater than 50 psi differential
Specifications Thread
Male
