Brass Threaded Insert Ball Check Valve with Metal Seat
Brass Threaded Insert Ball Check Valve with Metal Seat
SKU:CHE-6ab859
Durable Brass Threaded Insert Ball Check Valve for precise flow control in plumbing systems.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Brass Threaded Insert Ball Check Valve with Metal Seat
$29.99
Quantity: 1
Claim Your Seller Account
Brass Threaded Insert Ball Check Valve with Metal Seat
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Brass Threaded Insert Ball Check Valve with Metal Seat is a reliable solution for controlling flow in plumbing systems. Constructed with Brass and a 304 SS Ball, this valve ensures durability and efficient performance. With a maximum temperature of 300 °F and a cracking pressure of 15 psid, it meets the demands of various applications. The male threaded insert with O-ring seal provides secure connection and ease of installation. Ideal for both consumer and institutional use, this valve guarantees long-term reliability and compliance with industry standards.
Product Specifications
Dimensions Thread Size
7/16-20
Dimensions Total Length
0.781 in
Specifications Ball Material
304 SS
Specifications Connection A
7/16-20 UNF Threaded Insert O-ring seal
Specifications Cracking Pressure
15 psid
Specifications Cv
0.190
Specifications Material
Brass
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Thread
Male
