Brass Threaded Insert Ball Type Check Valves
Brass Threaded Insert Ball Type Check Valves
SKU:CHE-7ac0f1
Precision-engineered Brass Threaded Insert Ball Type Check Valves for reliable fluid control. Ideal for industrial applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Brass Threaded Insert Ball Type Check Valves
$29.99
Quantity: 1
Claim Your Seller Account
Brass Threaded Insert Ball Type Check Valves
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Brass Threaded Insert Ball Type Check Valves with Metal seat are precision-engineered for reliable performance in fluid control systems. Constructed with brass and a Viton seal, these valves ensure durability and optimal sealing properties. The 304 SS ball, with a cracking pressure of 6 psid, offers precise flow control up to 200 psig. With a male thread and 5/16-24 UNF Threaded Insert O-ring seal, these valves are designed to withstand temperatures up to 300 °F. Ideal for industrial applications requiring secure and efficient fluid regulation.
Product Specifications
Dimensions Thread Size
5/16-24
Dimensions Total Length
0.669 in
Specifications Ball Material
304 SS
Specifications Connection A
5/16-24 UNF Threaded Insert O-ring seal
Specifications Cracking Pressure
6 psid
Specifications Cv
0.081
Specifications Material
Brass
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Seal Material
Viton
Specifications Thread
Male
