Brass Threaded Insert Check Valves, Ball Type with Metal Seat
Brass Threaded Insert Check Valves, Ball Type with Metal Seat
SKU:CHE-39ea47
High-performance Brass Threaded Insert Check Valves with metal seat and Viton seal. Ideal for precise flow control.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Brass Threaded Insert Check Valves, Ball Type with Metal Seat
$39.99
Quantity: 1
Claim Your Seller Account
Brass Threaded Insert Check Valves, Ball Type with Metal Seat
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience superior performance with our Brass Threaded Insert Check Valves featuring a metal seat and Viton seal. Crafted with 304 SS ball and a male 10-32 UNF Threaded Insert for reliable sealing. These check valves offer a CV of 0.02, suitable for temperatures up to 150°F and pressures up to 125 psig. With a cracking pressure of 0 psid, they ensure efficient flow control in diverse applications.
Product Specifications
Dimensions Thread Size
10-32
Dimensions Total Length
0.425 in
Specifications Ball Material
304 SS
Specifications Connection A
10-32 UNF Threaded Insert O-ring seal
Specifications Cracking Pressure
0 psid
Specifications Cv
0.02
Specifications Material
Brass
Specifications Maximum Operating Pressure
125 psig
Specifications Maximum Temperature
150 ºF
Specifications Screened
None
Specifications Seal Material
Viton
Specifications Thread
Male
