Brass Threaded Insert Check Valves with 304 SS Ball - Metal Seat
Brass Threaded Insert Check Valves with 304 SS Ball - Metal Seat
SKU:CHE-1c81b3
Reliable Brass Check Valves with 304 SS Ball for backflow prevention. Ideal for high-temperature and high-pressure applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Brass Threaded Insert Check Valves with 304 SS Ball - Metal Seat
$29.99
Quantity: 1
Claim Your Seller Account
Brass Threaded Insert Check Valves with 304 SS Ball - Metal Seat
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our Brass Threaded Insert Check Valves with a 304 SS Ball and metal seat offer reliable backflow prevention. With a cracking pressure of 2 psid, these valves can operate at temperatures up to 300 °F and pressures up to 200 psig. The male 5/16-24 UNF Threaded Insert ensures a secure connection. The compact design with a total length of 0.669 in makes them ideal for various applications, providing durability and long-term performance.
Product Specifications
Dimensions Thread Size
5/16-24
Dimensions Total Length
0.669 in
Specifications Ball Material
304 SS
Specifications Connection A
5/16-24 UNF Threaded Insert O-ring seal
Specifications Cracking Pressure
2 psid
Specifications Cv
0.081
Specifications Material
Brass
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Thread
Male
