Bray Series 70 Actuator Battery Backup
Bray Series 70 Actuator Battery Backup
SKU:ACT-7d52f2
Reliable Battery Backup for Bray Series 70 Actuator for seamless operation in critical environments.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
Bray Series 70 Actuator Battery Backup
$299.99
Quantity: 1
Claim Your Seller Account
Bray Series 70 Actuator Battery Backup
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Bray Series 70 Actuator Battery Backup is a reliable solution designed for ensuring continuous operation in critical applications. This Battery Backup option, compatible with both On/Off and modulating actuators, features advanced circuitry that monitors battery strength, providing visual and remote indications of low battery status. Housed in a rugged NEMA 4X (IP 65) enclosure, this backup system offers seamless transition to user-selectable positions upon power loss, enhancing operational reliability and reducing downtime. With its versatile features and sturdy construction, the Bray Series 70 Actuator Battery Backup is an ideal choice for applications requiring dependable performance in various environments.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Battery Charging Temperature Limits
-4 to 122 ºF | -20 to 50 ºC
Specifications Battery Strength Alarm Contact Ratings
2 A
Specifications Charging Of Batteries
Continuous
Specifications Conduit Entries Wiring
3/4" NPT
Specifications Discharging Of Batteries
4.2A (Only upon loss of input power)
Specifications Features
Auxiliary Switches | Heater | Modulating | On/Off
Specifications Housing
Die Cast aluminum, Polyester finish, Nema 4X (IP 65)
Specifications Life Of Batteries
4 years, depended on ambient Temperature
Specifications Operating Temperature Limits
-4 to 122 ºF | -20 to 50 ºC
Specifications Power Requirements
24 to 27 VAC
Specifications Storage Temperature Limits
-40 to 140 ºF | -40 to 60 ºC
Specifications Terminal Block Wiring
Max 14 AWG
Specifications Torque
600 lb·in
Specifications Type Of Batteries
SLA (Sealed Lead Acid) Power Sonic PS1212 or Equal
