Bray Series 70 Industrial Electric Actuator
Bray Series 70 Industrial Electric Actuator
SKU:ACT-eb37aa
Rugged, compact industrial electric actuator with manual override handwheel, NEMA 4X/IP65 rated enclosure, and advanced modulating options for seamless control in various applications.
Regular price
$789.99
Regular price
Sale price
$789.99
Unit price
per
Initiate Order
Bray Series 70 Industrial Electric Actuator
$789.99
Quantity: 1
Claim Your Seller Account
Bray Series 70 Industrial Electric Actuator
$789.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Bray Series 70 Industrial Electric Actuator is a rugged and compact solution designed for a wide range of quarter turn applications. With torque outputs ranging from 600 to 18,000 lb.in., this actuator mounts directly to butterfly valves without the need for additional brackets. Featuring a manual declutchable override handwheel, NEMA 4X/IP65 enclosure, and compatibility with various analog control signals, the Bray Series 70 ensures ease of installation, commissioning, and service. With UL/CSA/CE approvals, internal isolation relays, and advanced modulating options, this actuator excels in cooling tower valves and outdoor applications.
Product Specifications
Specifications Agency Listings 120v
UL, CE, CSA
Specifications Ambient Temperature
-20 to 150 ºF | -29 to 65 ºC
Specifications Aux Switches Two Spdt
10A (1/2 HP) at 220 VAC | 10A (1/3 HP) at 120 VAC
Specifications Conduit Entries 2
70-0061, 1/2" NPT | All Other Models, 3/4" NPT
Specifications Features
120 VAC | Aux. Switches | Heater | Modulating
Specifications Full Load Current Draw
0.78 A
Specifications Heater Optional
5 Watt, PTC style, self regulating
Specifications Housing
Die Cast Aluminum, Polyester Finish | NEMA 4X, IP 65
Specifications Locked Rotor Current Draw
2.1 A
Specifications Motor Duty Cycle
Continuous Duty
Specifications Note
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these specifications, consult the nearest Bray office. Bray controls shall not be liable for damages resulting from misapplication or misuse of its products.
Specifications Servo Modulating Models
Control Input - 0 to 10 VDC, 2 to 10 VDC, 0 to 5 VDC, 4 to 20 mA | Input Impedance - Voltage: 1000K Ohms; Current: 250 Ohms
Specifications Stroke Time
30 sec
Specifications Terminal Strip
14 to 24 AWG
Specifications Torque Output
1200 in·lbs
Specifications Voltage
120 VAC
