The Bray Series 70 Industrial Electric Actuator is a rugged and compact solution designed for a variety of quarter turn applications such as butterfly valves and ball valves. With torque outputs ranging from 600 to 18,000 lb.in, this actuator mounts directly onto Bray and industry standard valves, eliminating the need for extra brackets. Featuring a manual declutchable override handwheel, NEMA 4X and IP65 enclosure ratings, and advanced Servo Pro modulating control, the Bray Series 70 assures compatibility with analog control signals, making it ideal for outdoor applications like cooling tower valves. The actuators meet UL, CSA, and CE standards for assured quality and performance.
Product Specifications
Specifications Agency Listings 120v
UL, CE, CSA
Specifications Ambient Temperature
-20 to 150 ºF | -29 to 65 ºC
Specifications Aux Switches Two Spdt
10A (1/2 HP) at 220 VAC | 10A (1/3 HP) at 120 VAC
Specifications Conduit Entries 2
70-0061, 1/2" NPT | All Other Models, 3/4" NPT
Specifications Features
120 VAC | Aux. Switches | On/Off
Specifications Full Load Current Draw
0.78 A
Specifications Heater Optional
5 Watt, PTC style, self regulating
Specifications Housing
Die Cast Aluminum, Polyester Finish | NEMA 4X, IP 65
Specifications Locked Rotor Current Draw
2.1 A
Specifications Motor Duty Cycle
Continuous Duty
Specifications Note
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these specifications, consult the nearest Bray office. Bray controls shall not be liable for damages resulting from misapplication or misuse of its products.
Specifications Servo Modulating Models
Control Input - 0 to 10 VDC, 2 to 10 VDC, 0 to 5 VDC, 4 to 20 mA | Input Impedance - Voltage: 1000K Ohms; Current: 250 Ohms
Specifications Stroke Time
30 sec
Specifications Terminal Strip
12 to 22 AWG
Specifications Torque Output
1200 in·lbs
Specifications Voltage
120 VAC
