The Bray Series 70 Industrial Electric Actuator offers a robust and compact solution for various quarter-turn applications such as butterfly valves, ball valves, and dampers. With torque outputs ranging from 600 to 18,000 lb.in. (68 to 2033 Nm), this actuator mounts directly onto Bray and other standard butterfly valves without requiring additional brackets or linkages. Featuring a manual declutchable override handwheel and a high visibility position indicator, this UL, CE, CSA approved actuator ensures easy installation, commissioning, and service. The NEMA 4X and IP65 rated enclosure with an industrial polyester finish makes it ideal for outdoor applications, including cooling tower valves. The advanced Servo Pro modulating option offers compatibility with a wide range of analog control signals used in modern building automation and temperature control systems. The Bray Series 70 Electric Actuator is designed to fit in tight spaces, provide universal application acceptability, assist in field operation, and return to a predetermined position in case of power supply loss, making it a reliable choice for industrial needs.
Product Specifications
Specifications Agency Listings 120v
UL, CE, CSA
Specifications Ambient Temperature
-20 to 150 ºF | -29 to 65 ºC
Specifications Aux Switches Two Spdt
10A (1/2 HP) at 220 VAC | 10A (1/3 HP) at 120 VAC
Specifications Conduit Entries 2
70-0061, 1/2" NPT | All Other Models, 3/4" NPT
Specifications Features
120 VAC | Aux. Switches | Modulating
Specifications Full Load Current Draw
1.0 A
Specifications Heater Optional
5 Watt, PTC style, self regulating
Specifications Housing
Die Cast Aluminum, Polyester Finish | NEMA 4X, IP 65
Specifications Locked Rotor Current Draw
1.4 A
Specifications Motor Duty Cycle
Continuous Duty
Specifications Note
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these specifications, consult the nearest Bray office. Bray controls shall not be liable for damages resulting from misapplication or misuse of its products.
Specifications Servo Modulating Models
Control Input - 0 to 10 VDC, 2 to 10 VDC, 0 to 5 VDC, 4 to 20 mA | Input Impedance - Voltage: 1000K Ohms; Current: 250 Ohms
Specifications Stroke Time
30 sec
Specifications Terminal Strip
14 to 24 AWG
Specifications Torque Output
600 in·lbs
Specifications Voltage
120 VAC
