Bray Series 70 Industrial Electric Actuator
Bray Series 70 Industrial Electric Actuator
SKU:ACT-c5ff54
Rugged and compact Bray Series 70 Industrial Electric Actuator with advanced control features and high reliability for various industrial applications.
Regular price
$799.99
Regular price
Sale price
$799.99
Unit price
per
Initiate Order
Bray Series 70 Industrial Electric Actuator
$799.99
Quantity: 1
Claim Your Seller Account
Bray Series 70 Industrial Electric Actuator
$799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Bray Series 70 Industrial Electric Actuator is a rugged and compact solution for various quarter-turn applications, such as butterfly valves and ball valves. With torque outputs ranging from 600 to 18,000 lb.in., this actuator mounts directly to industry standard valves without the need for additional brackets. Featuring a manual declutchable override handwheel and NEMA 4X/IP65 enclosure, it ensures ease of installation and service. The advanced Servo Pro modulating control card allows seamless integration with analog control signals, making it ideal for building automation systems. This actuator meets UL, CSA, and CE standards, offering reliability and versatility for industrial applications.
Product Specifications
Specifications Agency Listings 120v
UL, CE, CSA
Specifications Ambient Temperature
-20 to 150 ºF | -29 to 65 ºC
Specifications Aux Switches Two Spdt
10A (1/2 HP) at 220 VAC | 10A (1/3 HP) at 120 VAC
Specifications Conduit Entries 2
70-0061, 1/2" NPT | All Other Models, 3/4" NPT
Specifications Features
24 VAC | Aux. Switches | Heater | Modulating
Specifications Full Load Current Draw
2.0 A
Specifications Heater Optional
5 Watt, PTC style, self regulating
Specifications Housing
Die Cast Aluminum, Polyester Finish | NEMA 4X, IP 65
Specifications Motor Duty Cycle
Continuous Duty
Specifications Note
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these specifications, consult the nearest Bray office. Bray controls shall not be liable for damages resulting from misapplication or misuse of its products.
Specifications Servo Modulating Models
Control Input - 0 to 10 VDC, 2 to 10 VDC, 0 to 5 VDC, 4 to 20 mA | Input Impedance - Voltage: 1000K Ohms; Current: 250 Ohms
Specifications Stroke Time
60 sec
Specifications Terminal Strip
14 to 24 AWG
Specifications Torque Output
2000 in·lbs
Specifications Voltage
24 VAC
