Bray Series 70 Industrial Electric Actuator
Bray Series 70 Industrial Electric Actuator
SKU:ACT-1740e3
Rugged Bray Series 70 Actuator for precise quarter-turn applications. UL, CSA, CE approved with servo control options. NEMA 4X, IP65 rated.
Regular price
$899.99
Regular price
Sale price
$899.99
Unit price
per
Initiate Order
Bray Series 70 Industrial Electric Actuator
$899.99
Quantity: 1
Claim Your Seller Account
Bray Series 70 Industrial Electric Actuator
$899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Bray Series 70 Industrial Electric Actuator is a robust solution for quarter turn applications such as butterfly valves, ball valves, and dampers. With torque outputs ranging from 600 to 18,000 lb.in. and NEMA 4X, IP65 rated enclosures, it meets ISO 5211 standards for direct mounting. Featuring a manual declutchable override handwheel and high visibility beacon position indicator, this actuator offers universal application acceptability and field operation convenience. Equipped with advanced servo control options, internal isolation relays, and UL, CSA, and CE approvals, the Series 70 ensures seamless integration with various control systems.
Product Specifications
Specifications Agency Listings 120v
UL, CE, CSA
Specifications Ambient Temperature
-20 to 150 ºF | -29 to 65 ºC
Specifications Aux Switches Two Spdt
10A (1/2 HP) at 220 VAC | 10A (1/3 HP) at 120 VAC
Specifications Conduit Entries 2
70-0061, 1/2" NPT | All Other Models, 3/4" NPT
Specifications Features
24 VAC | Aux. Switches | On/Off
Specifications Full Load Current Draw
1.8 A
Specifications Heater Optional
5 Watt, PTC style, self regulating
Specifications Housing
Die Cast Aluminum, Polyester Finish | NEMA 4X, IP 65
Specifications Motor Duty Cycle
Continuous Duty
Specifications Note
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these specifications, consult the nearest Bray office. Bray controls shall not be liable for damages resulting from misapplication or misuse of its products.
Specifications Servo Modulating Models
Control Input - 0 to 10 VDC, 2 to 10 VDC, 0 to 5 VDC, 4 to 20 mA | Input Impedance - Voltage: 1000K Ohms; Current: 250 Ohms
Specifications Stroke Time
45 sec
Specifications Terminal Strip
12 to 22 AWG
Specifications Torque Output
600 in·lbs
Specifications Voltage
24 VAC
