The Bray Series 70 Industrial Electric Actuator offers a robust solution for various quarter-turn applications such as butterfly valves, ball valves, and dampers. Ranging from 600 to 18,000 lb.in. torque outputs, this compact actuator mounts directly onto Bray and other standard valves without the need for additional brackets. Featuring NEMA 4x and IP65 rated enclosures, it is ideal for outdoor applications. With manual declutchable override, high visibility position indicators, and advanced Servo Pro modulating options, the Series 70 ensures easy installation, universal compatibility, and reliable performance.
Product Specifications
Specifications Agency Listings 120v
UL, CE, CSA
Specifications Ambient Temperature
-20 to 150 ºF | -29 to 65 ºC
Specifications Aux Switches Two Spdt
10A (1/2 HP) at 220 VAC | 10A (1/3 HP) at 120 VAC
Specifications Conduit Entries 2
70-0061, 1/2" NPT | All Other Models, 3/4" NPT
Specifications Features
120 VAC | Aux. Switches | Heater | On/Off
Specifications Full Load Current Draw
1.6 A
Specifications Heater Optional
5 Watt, PTC style, self regulating
Specifications Housing
Die Cast Aluminum, Polyester Finish | NEMA 4X, IP 65
Specifications Locked Rotor Current Draw
3.0 A
Specifications Motor Duty Cycle
Continuous Duty
Specifications Note
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these specifications, consult the nearest Bray office. Bray controls shall not be liable for damages resulting from misapplication or misuse of its products.
Specifications Servo Modulating Models
Control Input - 0 to 10 VDC, 2 to 10 VDC, 0 to 5 VDC, 4 to 20 mA | Input Impedance - Voltage: 1000K Ohms; Current: 250 Ohms
Specifications Stroke Time
30 sec
Specifications Terminal Strip
12 to 22 AWG
Specifications Torque Output
5000 in·lbs
Specifications Voltage
120 VAC
